Welcome to SUPERLEAD
4G LTE, Global band
Bluetooth 5.0, low power, long distance perfect matching wireless printer
New generation slim 2D imager scan engine
Support megapixel versions
Licensed Datalogic decoding technology
IP65 industrial protection
Large battery capacity but refined power consumption, 3 hours charging time but 15 hours working duration, 32days standby duration
Free to install APPLOCK, Easy Deploy and other system management software for efficient management and deployment
Accurate Reading Ability, only decode barcode label that's close to the center of the aiming pattern, even when many labels are crowded
Application scenarios: manufacturing, warehousing and logistics, public utilities, retail, medical equipment integration, mobile payment, etc
| Platform and OS Features | |
| OS | Android 9 |
| CPU | Quad /Octa Core, 2GHz, 12nm |
| MEMORY | 2+16 |
| Extend Slot | MicroSD, support SDHC up to 64GB |
| One micro SIM connector | |
| PC Communication | USB 2.0 OTG; Type-C; Support Type-C Headset |
| Sensors | Light, Proximity, 3D G sensor, Hall, E-compass |
| LED | Charging, Scan and System status |
| Charging Time | 3 hours |
| Operation Duration | 15 hours |
| Data Collection | |
| Scan Engine | Mobydata E3200/E3250 |
| Post | Australian Post; British Post; China Post; 1MB; Japanese Post |
| KIX Post; Korea Post; Planet Code; Postnet; Royal | |
| Mail Code (RM4SCC) | |
| NFC(2.0 version) | 13.56MHz NFC |
| WPAN | BT 5.0/BLE |
| Environmental Specifications | |
| Operation Temperature | -25℃ ~ +55℃ |
| Storage Temperature | -30℃ ~+ 70℃ |
| Humidity | 5%-95% |
| Drop | 1.5m, concrete |
| Tumble | 600hits, 0.5m, Steel |
| IP | IP65 |
| ESD | ±8kV Contact, ±15kV Air |
| Keypad lifecycle | 300K |
| Physical Specifications | |
| LCD | 4.0 inch, 800*480. visible under sunshine |
| Touch | GFF Capacitive Touch |
| Camera | Auto focus 8Mega, with fash LED |
| Keypad | 24 Numeric Keypad |
| Left/Right Scan Key, Left/Right K1, K2 user-defined Key | |
| Back, Home, Switch | |
| Receiver | Support |
| Speaker | Min 90db at 10cm-1KHz Voice |
| Mic | Noise Reduction Mic |
| Charging 10 | USB Type-C |
| Charging Pad | |
| Battery | Removable 4000mAh |
| Dimension | 160mmx71mmxl 7 mm |
| Weight | 269g |
