Super large scanning window，large reading range
self-induction image reading
Support motion reading, scanning sensitivity
3 working modes( normal mode, mobilephone mode, fast moving mode)
Object self induction
Build in RS232 and USB interface
Super large reading window
3 working modes (normal mode, mobile phone screen mode and fast moving mode)
shopping malls, supermarkets, restaurants, tea shops, small and micro stores, warehousing and logistics, customer service front desk, etc
Large Field of View
Emotional Design
| Suzhou SuperMax Smart System Co., Ltd. | 7350 Technical Specification | |
| Physical Characteristics | ||
| Dimensions: | 150mm x 95mm x 98mm | |
| Weight: | 295g | |
| Voltage: | 5 VDC15% | |
| Current: | 500mA (Operating) | |
| Performance Characteristics | ||
| Light Source: | illumination: 617nm RED LED | |
| Field of View: | 55°(H)x 47°(V) | |
| Roll / Pitch / Yaw: | 360°, ±65°, ±60° | |
| Print Contrast: | 15% minimum reflective difference | |
| Motion Tolerances | up to 200 cm per second | |
| Interfaces Supported: | USB, RS232 | |
| Image (Pixels) : | 1280 pixels (H)x 1080pixels (v) | |
| Symbology Decode Capability | 1-D: | UPC，EAN,Code128, Code 39, Code 93, Code11，Matrix 2 of 5, Interleaved 2 of 5, Codabar , etc. |
| 2-D: | PDF417,Data Matrix,Maxicode, QR Code,Aztec, etc. | |
| Minimum Resolution: | 3 mil Code39 | |
| User Environment | ||
| Operating Temperature: | 0℃ to 50°C | |
| Storage Temperature: | -40℃ to 70°c | |
| Humidity: | 0% to 95% relative humidity,non-condensing | |
| Drop Specifications: | Designed to withstand 1m drops | |
| Ambient Light lmmunity: | 100.000 Lux. | |
| Decode Ranges | ||
| 3.13mil C39 | 30mm-50mm | |
| 4.7mil C39 | 30mm-80mm | |
| 5.13mil c39 | 20mm-115mm | |
| 6.88mil PDF | 0mm-160mm | |
| 10mil DM | 10mm-180mm | |
| 20mil QR | 0mm-230mm | |
| Performance may be impacted by bar code quality and environmental conditions. | ||
